In the construction industry of many countries, laws and regulations mandate comprehensive quality monitoring during the building process to safeguard the stability and safety of infrastructure projects. For critical civil engineering undertakings—such as bridges, dams, subways, and tunnels—rigorous monitoring is essential. Among the tools commonly employed, inclinometers stand out as vital instruments in geotechnical safety monitoring. They are frequently used to track horizontal displacements within deep soil layers for projects like bridges, dams, foundations, and other geotechnical works. This article explores six key projects where inclinometer monitoring is essential, examining the reasons why this monitoring is crucial.
Bridges are vital public infrastructures where safety is paramount. Slight inclinations in bridges during high winds, earthquakes, or heavy loads can signal potential structural risks. So real-time data and immediate warnings from an inclinometer are essential for effective bridge structural monitoring. Besides, in building monitoring projects, environmental factors like temperature, humidity, and vibrations also affect data accuracy. Our automated inclinometer, Inclino-Robot with high accuracy provides timely data and alerts engineers to any shifts that could indicate structural strain or instability.
The advantages of Inclino-Robot in bridge monitoring include:
Real-time remote monitoring and data output: Inclino-Robot can realize 24-hour remote inclinometer monitoring with timely automated data collection and transmission.
High-accuracy: Inclino-Robot follows the same measurement process as manual inclinometers and it ensures unparalleled accuracy with precision up to 0.25mm/m has been validated across numerous projects, matching that of a manual inclinometer.
Download the test results: Test Results of Inclino-Robot and a traditional manual inclinometer.pdf
Inclinometers are essential in foundation pit monitoring, as they measure the deformation of retaining walls and calculate displacement across piles at various depths. These measurements help engineers identify signs of soil instability early on. Excavation pits deeper than 30 meters require accurate and cost-effective monitoring solutions. Our inclinometer’s measurement cost remains consistent with measurement points every 0.5 meters, regardless of excavation pit depth, as it requires only one probe and a single sensor fixed to one side of the steel wire rope, which is driven up and down by the drive controller. While traditional inclinometers become increasingly expensive with increasing depths.
The advantages of Inclino-Robot in bridge monitoring includes:
· The cost remains mostly consistent when the excavation depths increase (especially for depths up to 30 meters)
· Multiple prices for options: It is available in four price ranges: 30, 45, 60, and 100 meters
· Stable data accuracy with precision up to 0.25mm/m: At greater depths, manually pulling the inclinometer can compromise the stability and accuracy of measurements. However, automated inclinometers ensure consistent precision and reliability.
Monitoring slopes, especially those prone to landslides, collapse, and other geological risks, is essential for road and public safety. Traditional inclinometers are challenging to install on uneven terrains, where monitoring points need to align with varying soil thicknesses. Traditional manual monitoring often falls short in efficiency and real-time alert, increasing the risk for road infrastructure. Besides, the Inclino-Robot integrated with GNSS, water-level gauges, rain gauges, and total stations from our GeoSitter company (focus on manufacturing of various geotechnical monitoring instruments), provides a comprehensive solution for slope monitoring.
Except for the feature of real-time data transmission and alert mentioned above, Inclino-Robot in slope monitoring systems are essential because:
Easy and efficient: One person is sufficient to install the Inclino-Robot and handle multiple projects with Inclino-Robot. Traditional inclinometers require manual measurements, with each borehole taking about 30 minutes. Consequently, measuring 25 boreholes would take a minimum of 12 hours. Inclino-Robot only needs 3 hours to complete the project, including the test report.
Reservoirs and dams are often located in harsh environmental conditions, like remote, humid, or flood-prone areas where traditional inclinometers may struggle to withstand these challenging environmental conditions, leading to measurement errors or equipment damage.
Besides, dams have large and complex structures, requiring frequent manual installation and maintenance of traditional inclinometers at various locations. This process is cumbersome and costly. Finally, due to the high humidity and temperature fluctuations common in dam environments, traditional monitoring instruments may experience measurement errors or malfunctions over time, affecting the long-term accuracy and stability of the monitoring system.
In addition to its stable data accuracy with high precision, and easy, efficient installation and operation, the Inclino-Robot is essential for dam and reservoir monitoring projects because:
Waterproof: It is designed for submerged installation, operates effectively underwater, and withstands flooding.
Low power consumption: It is both supported by solar energy and external power, it can be installed in difficult-to-access areas while providing precise data.
In tunnels, slight shifts caused by vehicular or train movement can indicate potential structural issues. Traditional inclinometers struggle with data transmission in deep tunnel settings where network coverage is limited, and signal degradation increases with distance. Our automated inclinometer, equipped with robust 4G communication capabilities consistently transmits high-quality data from deep tunnel locations. And we can also modify data format according to clients’ data templates, like CSV. This real-time, high-precision monitoring system generates alerts based on inclinations, making it a reliable tool for early warning in tunnel infrastructure.
In open-pit mines, safety is a significant concern due to frequent mining activities, heavy machinery, and environmental influences like rain and blasting. There is a monitoring case from one of our clients:
In a certain region, there is a large limestone mine that has been a constant focus of safety concerns. To ensure safe production, a mine safety monitoring project was implemented. The mine features a vertical height difference of 230 meters, with designed bench heights of 12 meters, a working slope angle of 65°, and a final slope angle of 52°. The minimum transportation platform width is ≥30 meters, and the working line length is ≥55 meters. Such a complex geographical environment posed significant challenges for the installation of monitoring equipment.
After conducting thorough market research, the client chose our Inclino-Robot. He mentioned two key factors that particularly impressed him:
Labor saving and remote monitoring:
Inclino-Robot is easy to install and operate, requiring minimal personnel intervention—one person can operate multiple units simultaneously. With remote monitoring and alert features, it greatly reduces on-site risks and provides dependable data to maintain mining safety standards.
Inclinometers play a crucial role in ensuring the safety and stability of critical infrastructure projects like bridges, dams, tunnels, and mines. Our Inclino-Robot offers superior accuracy, cost-efficiency, and ease of use compared to traditional methods, making it an ideal solution for real-time, remote monitoring. With its ability to operate in challenging environments and provide timely alerts, Inclino-Robot helps engineers detect potential issues early, reduce risks, and maintain long-term stability. By choosing advanced monitoring technology like the Inclino-Robot, projects can enhance safety, streamline operations, and safeguard infrastructure.
After all, due to the variations in geology, environment, and monitoring standards for each project, it is essential to adopt a tailored approach and establish a corresponding monitoring solution to ensure the smooth construction and operation of the project. For customized monitoring solution, contact us by email: rebeccayang@ougangroup.com and phone: +8613868064820
